WP400-3

WP400-3

Field Probe 1 Hz – 400 kHz

功能特點 (Features):
電場與磁場測量 (Electric & Magnetic field measurement)
各向同性與真實均方根測量 (Isotropic & True RMS measurement)
頻譜分析探頭 (Spectrum analysis probe)
符合國際標準的測量 (Measurements in accordance with International Standards)


主要應用 (Main Applications):
焊接:IEC/EN 62822, EN 50505 (Welding equipment: IEC/EN 62822, EN 50505)
家用電器:IEC/EN 62233, EN 50366 (Household appliances: IEC/EN 62233, EN 50366)
其他電子/電氣設備:IEC/EN 62311 (Other electronic/electrical equipment: IEC/EN 62311)
研究/實驗室 (Research/Labs)
其他需要小型化及空間解析度的應用 (Other applications where small size and spatial resolution is important)
符合 IEC/EN 61786-1 (In accordance with IEC/EN 61786-1)

詳細說明

  Electric Field Magnetic Field
Sensor type Isotropic electrode Isotropic 3 cm2 coils
Frequency range 1 Hz – 400 kHz
Field Strength Mode
Measurement range  10 V/m to 400 kV/m 200 nT - 50 mT (100 Hz - 10 kHz)
· Upper range increases linearly with
decreasing frequency below 100 Hz.
· Upper range decreases linearly with
increasing frequency above 10 kHz.
Graphical display RMS, Axis Values, AVG, MAX, MIN, PEAK, RMS time graph
Peak value digital realtime digital realtime
Resolution < 0.4 mV/m above 8 Hz < 0.3 nT (at 50 Hz) and
< 0.15 nT above 100 Hz
Noise level < 10 V/m (10 Hz - 400 kHz) < 200 nT (10 Hz - 400 kHz)
Typical Uncertainty
(10 Hz - 100 kHz)
8 % (0.67 dB)  7.2 % (0.60 dB)
Weigthed Peak Method mode
Measurement range 200 % (min) 200 % (min)
Graphical display PEAK (%), AXIS VALUES (%), AVG (%), MAX (%), MIN (%), RMS (%),
Time graph
Standards/Limits Standards / Limits EU Directive 2013/35/EU, FCC/IEEE, ICNIRP 1998
workers, ICNIRP 2010 workers, BGV B11
Easy software update to future modifications and to other limits.
Typical Uncertainty
(10 Hz - 100 kHz)
8 % (0.67 dB)  7.2 % (0.60 dB)
FFT Mode
Measurement range 40 mV/m to 400 kV/m 2 nT to 50 mT (100 Hz - 10 kHz)
· Upper range increases linearly with
decreasing frequency below 100 Hz.
· Upper range decreases linearly with
increasing frequency above 10 kHz.
Graphical display Frequency analysis, total field and axes
SPAN(Resolution) 400 Hz (1 Hz) - 4 kHz (10 Hz) - 40 kHz (100 Hz) - 400 kHz (1 kHz)
Noise level < 40 mV/m < 1.8 nT
FFT 1024 point FFT
General specifications
Isotropy ± 5 % ± 4 %
Typical Uncertainty  8 % (0.67 dB) 7.2 % (0.60 dB)
Temperature deviation
[typ. at 60 Hz]
(referred to 25 °C,
50 % relative humidity)
- 0.005 dB/°C (- 15 °C to 40 °C) - 0.003 dB/°C (- 15 °C to 25 °C)
+ 0.003 dB/°C (25 °C to 40 °C)
Damage level > 600 kV/m > 5000 mT up to 60 Hz
Damage level decreases linearly with
increasing frequency above 60 Hz
Linearity ± 1 % (typ.)
± 2 % (max.)
Weight 125 g
Probe size 275 x 33 mm Ø
